Note: Assignment switching works n conjunction with AUX "E" Pan
control 54.
SUB 3 SECTION
PAN (59)
For stereo operation, a AN is used to ‘crcsstade’ the Subnaster to the
center left, or right n the L-R '‘stereo image" For mono operation, PAN
assigns the Submaster output to the Left or Right Masters.
PFL (60)
The "in' position of this switch assgns Sub 3 to PFL.
SUB 3 (61)
This fade' sets the level of Submaster 3.
AUX F RETURN SECTION
TO AUX A (62)
Allows the AUX "F" return :o be assigned io die AUX "A" mix.
TO AUX B (63)
Allows the AUX "F" return :o be assigned to the AUX "B" mix.
LEVEL (64)
Controls the level of the AUX "F" Return. When an outboard effects
device is patched into the AUX ' F" paten cop, this control determines
the level of the effect that is routed thru the AUX "F" Pan control.
PAN (65)
.Assigns AUX "F" Return :o L & R, or Subs 1 2. 3. anc 4. Musi be
used in conjunction with assignment switches 67 thru 69
PFL (66)
The "in" position of this switch assigns the AUX “F 1 Return to PFL
L-R (67)
The "in" position oi this switch rau'es the AUX "F” Return thru
AUX "F" Pan control directly "O left, right, or both. The "Out" position
removes AUX '"F" from L and R.
1-2 ( 68 )
The "in" position of this switch routes the AUX "F" Return thru
AUX "F' Pan control to Sub 1 Sub 2 or both. The ’out" position
'emoves AUX "F" from Subs 1 and 2.
3-4 (69)
The "in" position of this switch routes the AUX "F" Roturn thru
AUX "F" Pan control to Sub 3, Sub 4 or both. The "out" position
removes AUX "F" from Subs 3 and 4.
Note: Assignment switching works in conjunction with AUX "F" Pan
control 65.
SUB 4 SECTION
PAN (70)
For stereo operation. PAN is used to "crossfade" the Submaster to the
center eft. or right in the L-R "stereo image." For mono operation, PAN
assigns the Submast©' output to the Left or Right Masters.
PFL (71)
The "in" position of this switch assigns Sub 4 to PFL
RIGHT (75)
Master Fader for all enamels and Submasters assigned to the RIGHT.
Determines the overall Right Main mix level.
POWER SWITCH (76)
Depress the switch to the "On" oosition. The red power LED (7t) will
illuminate indicating power is being supplied to the unit
LAMP (77)
A 2-pin XLR jack is provided fo r connecting an optional gooseneck
mixer lamp (Model ML-2) for nomination in adverse lighting conditions.
STEREO OUT (78)
Adjusts the Left anc Right signal level to the STEREO OUT jack. Signals
are taken before (Pre) the LEFT and RIGHT Mam Faders.
MASTER (79)
Controls the overall mix level when the mixer is operated in the mcno
configuration (4x2x1) MASTER s the combination of the Main LEFT
and RIGHT signals and the MASTER AUX In.
HEADPHONE LEVEL (80)
Adjusts the level of L/R signals at the HEADPHONE jack, unless the
PFL signal is present.
PFL LEVEL (81)
Controls the level lor any "pre fade listen” (PFL) source, selected on
the mixer and sends this signal to the headphones. One or more PFL
switches must be engaged before this central is active. PFL LED in¬
dicates when the PFL is active NOTE: When the PFL is active, it over
rides Stereo L/R in the headphones
HEADPHONE JACK (82)
This stereo ack allows signal to flow to both sdes ot any stereo headset.
Tip = Left, Ring = Right.
AUX MASTERS/PFL (83)
Six AUX MastC'S arc provided (one for each of the 6 AUX sends). Each
AUX Master control regulates the overall mix level appearing at the
AUX output jack. Each AUX Master is equipped with a PFL switch.
The "in" position ot this switch assigns the AUX to PFL
OPERATIONAL NOTE: (84)
The AUX mix capability of this console provides control over Monitor
and Effects mixing. Monitor mixes are normally configured PRE at the
channe faders (see Pre/Post switch AUX C and D). The AUX Masters
become Monitor Master controls in this configuration, controlling the
signs level at the AUX output jack. Effects mi:<es are normally con¬
figured POST at tne channel faders. The AUX Masters become Effect
Master controls in this contiguration. controlling the signal leve at the
AUX output jack.
AUX A ar>d B sends are internally set PRE and should be the ob¬
vious choices for Monitor mixing. AUX E and F sends are internally
set POST and should be the obvious choices for Elects. AUX C and
D sends are switch-selectable (PRE or POST) anc may be configured
for either Effects or Monitors.
SUB 4 (72)
This fader sets the level of Submaster 4
POWER LED (73)
Illuminates when AC power is being supplied to the unit.
LEFT (74)
Master Fade' for all channels and Submaslers assigned to the LEFT
Determines the overal Led Main mix level.
