A
Intended
to
alert
the
user
to
the
presence
of
uninsulated
"dangerous
voltage"
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of
electric
shock
to
persons.
A
Intended
to
alert
the
user
of
the
presence
of
important
operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
Lhe
product.
CAUTION:
Risk
of
electrical
shock
-
DO
NOT
OPEN!
CAUTION:
To
reduce
the
risk
of
electric
shock,
do
not
remove
cover.
No
user
serviceable
parts
inside.
Refer
servicing
to
qualified
service
personnel.
WARNING:
To
prevent
electrical
shock
or
fire
hazard,
do
not
expose
this
appliance
to
rain
or
moisture.
Before
using
this
appliance,
read
the
operating
guide
for
further
warnings.
WARNING:
For
optimum
performance
and
reliability
DO
NOT
PRF.SI:NT
EACH
(either
of
the
two)
A
AMPLIFIER
WITH
A
SPEAKER
LOAD
OF
LESS
THAN
4
OHMS.
OR
A
COMBINATION
OF
SPEAKERS
THAT
TOGETHER
ARE
LESS
THAN
4
OHMS!
Using
one
speaker,
it
must
be
rated
at
4
ohms
minimum.
Using
two
speakers,
they
must
be
rated
each
at
8
ohms
minimum.
Thank
you
for
purchasing
the
Peavey
XRD
680S
mixer
with
built-in
stereo
digital
effects
and
stereo
amplifiers.
This
is
a
powerful,
easy-to-use.
portable,
eight-channel
mixing
con¬
sole.
Your
XRD''
680S
features
a
rugged,
heavy-gauge
cold-rolled
steel
and
aluminum
chassis,
finished
in
oven-cured
epoxy
for
toughness
and
screen-printed
utilizing
the
latest
photo¬
graphic
film
and
U.V.-eured
ink
technology
for
razor-sharp,
hard-wearing
control
I.D.
and
calibration
graphics.
Every
on-board
component
has
been
carefully
chosen
to
deliver
the
highest
possible
perfor¬
mance.
Precision,
professional
reliability,
and
minimal
operating
noise
characteristics
are
only
the
initial
criteria
used
during
the
process
of
selecting
the
components
that
ensure
that
your
XRD
"
680S
becomes
an
indispensable
addition
to
your
live
performance
equipment.
All
printed
circuit
boards
are
constructed
from
rugged.
U.S.
military-spec
material
using
the
latest
automated
assembly
technology,
wave
solder,
and
computer-controlled
"all-faults-
analyzed-and-corrected"
Q.A.
procedures.
Each
channel
features
front-panel
output
and
monitor
level
controls,
as
well
as
high.
mid.
low
equalization
and
effects
emphasis
controls.
Every
input
channel
has
a
studio-quality,
low-impedance
(XLR-type
input)
microphone
input,
as
well
as
a
1/4"
line
input.
Switchable
+48
V
phantom
power
is
provided.
The
unit
features
stereo
150-watt
power
amplifiers.
