Pecron E3000 - Page 11

USING SOLAR PANELS TO CHARGE THE E3000
support@pecron.com
36V
36V
36V
36V
36V
Using the pecron 200W /36V*6（1200W）to charge the E3000
MC4 Solar Charging Cable*2
Y Branch MC4 Charging Cable(+)*2
Y Branch MC4 Charging Cable(-)*2
pecron 200W*6
※ 36V is the operating voltage of the solar panels
36V
36V
36V
