STRUCTURE OF THE ADVANCED PARAMETERS MENU
SELECT
LANG.CONFIG
• Sets the language of the VSP.
9
LANG.CONFIG
LANGUAGE:ENG
• Select the desired language (ITA-ENG-DEU-ESP-FRA)
SELECT
BASIC CONFIG
• Basic parameters setting
9
BASIC CONFIG
SETPOINT 4,2
SET PRESSURE
• Sets the system pressure value (constant)
Default 4.0 bar Range 1–10 bar Step 0,1 bar
BASIC CONFIG
SETPOINT2 4,0
SECOND SET PRESSURE
• Sets a second system pressure value (constant)
To enable it, congure the parameter IN2 in the menu CONF.INGR.
USC..
Default 4.0 bar Range 1–10 bar Step 0,1 bar
BASIC CONFIG
DELTAP 0,50
RESTART DIFFERENTIAL PRESSURE
• Sets the SET PRESSURE dierential and the actual start pressure.
Default 0.50 bar Range 0.1-1.00 bar Step 0,01 bar
BASIC CONFIG
T DRY 10
STOP DELAY FOR DRY RUNNING (External input)
• Sets the pump stop delay in dry run conditions for operation with IN1
input enabled to work with "FLUX= external minimum ow sensor".
To enable it, congure the parameter IN1 as FLUX in the menu CONF.
INGR.USC..
Default 10 sec Range 0–100 sec Step 1 sec
BASIC CONFIG
PAUSE TIME 10
DRY RUN RESTART INTERVAL
• Sets the interval between two subsequent automatic attempts to re-
start after stoppage due to a dry run.
• Setting the value to “0” bypasses the automatic attempts to restart.
Default 10 min Range 0–100 min Step 1 min
BASIC CONFIG
F.MIN.FLW
STOPPAGE FREQUENCY FOR MINIMUM FLOW
• Sets the frequency under which the ow is considered under the min-
imum operating ow.
Default (*) Hz Range 25–60 Hz Step 0,1 Hz
BASIC CONFIG
STOP TIME 3
STOP DELAY FOR NULL FLOW
• Sets the pump stoppage delay in the null ow condition.
Default 3 sec Range 1–15 sec Step 1 sec
BASIC CONFIG
REACTIONF 3
INVERTER REACTION RAPIDNESS
• Sets the rapidness of inverter response to pressure variations.
Default 3 Range 1–5 Step 1
Continued
(*) The DEFAULT value depends on the electric pump model associated with the VSP inverter
