| VSP
ADVANCED PARAMETERS MENU
If the default values have to be edited, the ADVANCED MENU contains all the advanced parameters of the VSP. The control
panel display will turn YELLOW.
List of parameters
CONFIG.
LINGUA
CONF.
BASE
CONF.
MOTORE
CONF.
SENS.PRE
CONF.
INGR.USC.
CONF.
GRUPPO
TEST PAR.
FABBRICA
9
LINGUA
9
SETPOINT
SETPOINT2
DELTAP
T.DRY
PAUSE TIME
F.MIN.FLW
STOP TIME
REACTIONF
9
CURRENT
ROTATION
F NOM
F LOW
F MAX
COSFI MIN
COSFI TIME
FS
9
1 TYPE
RANGE
2 TYPE
RANGE
MODE
9
IN1
TYPE IN1
IN2
TYPE IN2
IN3
TYPE IN3
OUT1
TYPE OUT1
OUT2
TYPE OUT2
9
MODE
TYPE
NO COM
9
FREQ
CURRENT
COSFI
TEMP. MOD
VOLTAGE
9
CONFERMI?
How to display the advanced menu parameters:
• Place the VSP out of service (STOP) pressing the ON/OFF key
(White Display)
• Simultaneously press the keys
+ + for more than 5 seconds (YELLOW Display)
• Press the keys
or to display the various MENUS on the alphanumerical display
• Press the key
to display the various parameters present.
How to edit the advanced menu parameters:
• Select the parameter to edit scrolling with the keys
or
• Press the key to enable the parameter selected.
• Press the
or key to edit the parameter value.
• Press the
key to conrm the choice.
• Press the
key to display the next parameter or the key to exit from the menu.
If the key
is pressed during editing the values without rstly pressing the key , the parameter is not
saved.
