PEDROLLO VSP User Manual

9
VSP |
POWER SUPPLY TERMINAL BOARD
The power terminals are dierent if the VSP is three-phase or mono-phase.
INPUTS/OUTPUTS TERMINAL BOARD
F
N
 F = MAINS SUPPLY PHASE
 N = MAINS SUPPLY NEUTRAL
VSP mono-phase terminals
1 ~ 230 V
VSP three-phase terminals
3 ~ 400 V
U
V
W
 U = MAINS SUPPLY PHASE
 V = MAINS SUPPLY PHASE
 W = MAINS SUPPLY PHASE
485_1_A
485_1_B
GND
GND
+5V
+24V
+24V
AN1
AN2
GND
GND
COM_1
NO_1
NC_1
COM_2
NO_2
NC_2
GND
IN3
GND
IN1
IN2
485_2_A
485_2_B
4-20
mA
4-20
mA
 FIRST SERIAL COMMUNICATION RS485 (D +)
 FIRST SERIAL COMMUNICATION RS485 (D -)
 FIRST SERIAL COMMUNICATION RS485 (0 V)
 SECOND SERIAL COMMUNICATION RS485 (D +)
 SECOND SERIAL COMMUNICATION RS485 (D -)
 SECOND SERIAL COMMUNICATION RS485 (0 V)
 ANALOGUE INPUT SUPPLY TYPE 0–5 V
 ANALOGUE INPUT SUPPLY TYPE 4–20 mA
 FIRST ANALOGUE INPUT
 REFERENCE POWER (0 V)
 FIRST DIGITAL INPUT
 SECOND DIGITAL INPUT
 REFERENCE POWER (0 V)
 ANALOGUE INPUT SUPPLY TYPE 4–20 mA
 SECOND ANALOGUE INPUT
 REFERENCE POWER (0 V)
 THIRD DIGITAL INPUT
 REFERENCE POWER (0 V)
 COMON RELAY FIRST OUTPUT
 CONTACT (Normally Open NO) FIRST OUTPUT RELAY
 CONTACT (Normally Closed NC) FIRST OUTPUT RELAY
 COMMON RELAY SECOND OUTPUT
 CONTACT (Normally Open NO) SECOND OUTPUT RELAY
 CONTACT (Normally Closed NC) SECOND OUTPUT RELAY
COMMUNICATION 1
COMMUNICATION 2
AN1
IN1
IN2
AN2
IN3
OUTPUT 1 RELAY
OUTPUT 2 RELAY
