REPAIR PARTS
Table 11.2: Manifold, Gas Valve and Pilot
Description
Quantity
Required
Stock
Code
9
Steel Burner – MI-e-03 3 51537
Steel Burner – MI-e-04 5 51537
Steel Burner – MI-e-05 7 51537
Steel Burner – MI-e-06 9 51537
Steel Burner – MI-e-07 11 51537
Steel Burner – MI-e-08 13 51537
Steel Burner – MI-e-09 15 51537
9A Air Shutter with Screw, LP 1 per burner 7202
10 Steel Burner w/ Spark Pilot Bracket 1 51539
11
Gas Manifold – MI-e-03 1 50978
Gas Manifold – MI-e-04 1 50979
Gas Manifold – MI-e-05 1 50980
Gas Manifold – MI-e-06 1 50981
Gas Manifold – MI-e-07 1 50954
Gas Manifold – MI-e-08 1 50955
Gas Manifold – MI-e-09 1 50956
12
Orifice Spud, #48 Natural Gas – MI-e-03 4 50894
Orifice Spud, #48 Natural Gas – MI-e-04 6 50894
Orifice Spud, #48 Natural Gas – MI-e-05 8 50894
Orifice Spud, #48 Natural Gas – MI-e-06 10 50894
Orifice Spud, #48 Natural Gas – MI-e-07 12 50894
Orifice Spud, #48 Natural Gas – MI-e-08 14 50894
Orifice Spud, #48 Natural Gas – MI-e-09 16 50894
Orifice Spud, #56 LP Gas – MI-e-03 4 50899
Orifice Spud, #56 LP Gas – MI-e-04 6 50899
Orifice Spud, #56 LP Gas – MI-e-05 8 50899
Orifice Spud, #56 LP Gas – MI-e-06 10 50899
Orifice Spud, #56 LP Gas – MI-e-07 12 50899
Orifice Spud, #56 LP Gas – MI-e-08 14 50899
Orifice Spud, #56 LP Gas – MI-e-09 16 50899
13
Resideo VR8204A-2001 Gas Valve Spark – Natural Gas MI-e-03 thru MI-e-05 1 50583
Resideo VR8304P-4504 Gas Valve Spark – Natural Gas MI-e-06 thru MI-e-09 - 0.9” WC Step 1 50847
Resideo VR8204A-2103 Gas Valve Spark – LP Gas MI-e-03 thru MI-e-05 1 50584
Resideo VR8304P-4314 Gas Valve Spark – LP Gas MI-e-06 thru MI-e-09 - 1.4” WC Step 1 50724
13A
White Rodgers 36G33-530 Gas Valve Spark - Natural Gas MI-e-03 thru MI-e-05 (Alternate) 1 50797
White Rodgers 36G33-531 Gas Valve Spark - LP Gas MI-e-03 thru MI-e-05 (Alternate) 1 50799
13B
Robertshaw 7000BDER-S7C Gas Valve Spark - Natural Gas MI-e-06 thru MI-e-09 (Alternate) 1 50397
Robertshaw 7000BDER-LP-S7C Gas Valve Spark - LP Gas MI-e-06 thru MI-e-09 (Alternate) 1 50398
14
Resideo Q3481B-1644 Spark Pilot – Natural Gas MI-e-03 thru MI-e-09 1 50996
Resideo Q3481B-1529 Spark Pilot – LP MI-e-03 thru MI-e-09 1 50997
