REPAIR PARTS
Table 11.2
Description
Quantity
Required
Stock
Code
16 Insulation Blanket, 1/2" x 1.50", Block to Base – 50867
17
Block – PSCII-03 – 90419
Block – PSCII-04 – 90420
Block – PSCII-05 – 90421
Block – PSCII-06 – 90422
18
Flue Baffle – PSCII-03 2 51584
Flue Baffle – PSCII-04 3 51584
Flue Baffle – PSCII-05 4 51584
Flue Baffle – PSCII-06 5 51584
19 Insulation Blanket, 1/2" x .75", Flue Collector to Block – 50866
20
Flue Collector – PSCII-03 – 50171
Flue Collector – PSCII-04 – 50172
Flue Collector – PSCII-05 – 50173
Flue Collector – PSCII-06 – 50174
21 Gasket, Orifice Plate 2 50135
22
Orifice Plate, Normal Altitude Natural Gas Models Only – PSCII-03 – PSC5002
Orifice Plate, Normal Altitude Natural Gas Models Only – PSCII-04 – PSC5002-1
Orifice Plate, Normal Altitude Natural Gas Models Only – PSCII-05 – PSC5002-2
Orifice Plate, Normal Altitude Natural Gas Models Only – PSCII-06 – PSC5002-3
Orifice Plate, Normal Altitude LP Gas Models Only – PSCII-03 – PSC5003
Orifice Plate, Normal Altitude LP Gas Models Only – PSCII-04 – PSC5003-1
Orifice Plate, Normal Altitude LP Gas Models Only – PSCII-05 – PSC5003-2
Orifice Plate, Normal Altitude LP Gas Models Only – PSCII-06 – PSC5003-3
23 Fan – 50775
24 Fan Adapter – 50200
25
Jacket – PSCII-03 – 90729
Jacket – PSCII-04 – 90730
Jacket – PSCII-05 – 90731
Jacket – PSCII-06 – 90732
– Gas Valve, SV9501M2700, Natural Gas Models Only – 51682
– Gas Valve, SV9501M2064, LP Gas Models Only – 51691
– Pilot Assembly, Q3480B1058, w/ Natural Gas Orifice – 7794
– Pilot, Q3480B1058, LP Gas Models Only – 50205
– Limit Control, L4080B1253 (less well) – 50210
– Pressure Switch, Standard altitude, FS6124A2481 – 50080
– Transformer Relay Center, R8285D1026 – 50786
– Relay (mounted on jacket), R4222D1005 – 50790
– Safety Relief Valve, 30 PSI, Conbraco 10-408-05 – 50501
– Safety Relief Valve, 50 PSI, Watts #350 – 99950
– Temperature-Pressure Gauge – 51774
– Condensate Drain Elbow – 51185
– Outside Stainless Steel Vent Cap – 50139
– Wall Thimble (standard, up to 11-1/2" wall) – 50137
– Wall Thimble 20 (for a wall greater than 11-1/2" to 20") – 90350
– Inside Thimble Cap – 50138
– Inside Thimble Collar – 50158
– Screened Vent Termination – 50130
– Vent Clamp – 51900
Blower Gaskets
– Orifice Plate Gaskets 2 50135
– Fan Outlet Gasket – PSC5019
