PEERLESS Smartmount ST650 - Parts List; Non-Security Adapter Bracket Fasteners

3 of 27
ISSUED: 11-21-07 SHEET #: 202-9255-2 02-22-08
Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870
DD
EE
AA BB
FF
Non-SecurityAdapter Bracket Fasteners
M4 x 12 mm (6)
(504-9013)
M5 x 12 mm (4)
(520-1027)
M8 x 16 mm (6)
(520-9257)
I.D. .34" (8.6 mm) (4)
(540-1059)
I.D. .22" (5.6 mm) (4)
(540-1057)
M6 x 30 mm (4)
(510-9109)
M6 x 12 mm (4)
(520-1128)
M6 x 25 mm (4)
(520-1208)
M6 x 20 mm (4)
(520-9402)
multi-washer (6)
(580-1036)
NOTE: The sorted-for-you™ fastener pack included was made specifically for your product and may not contain all components
shown below.
M4 x 25 mm (4)
(504-1015)
M5 x 25 mm (4)
(520-9543)
M8 x 40 mm (4)
(520-1136)
M8 x 25 mm (4)
(520-1031)
CC
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
Security Non-Security
Qty.
Black Part
Number
Silver
Part Number
Black
Part Number
Silver
Part Number
AA
wall plate 1
201-1504 201-4504 201-1504 201-4504
BB
right adapter bracket 1
201-1470 201-4470 201-1469 201-4469
CC
left adapter bracket 1
201-1472 201-4472 201-1471 201-4471
DD
4
5S1-015-C03 5S1-015-C03 5S1-015-C03 5S1-015-C03
EE
4
590-0097 590-0097 590-0097 590-0097
FF
1
560-1146 560-1146 N/A N/A
Parts List
4 mm allen wrench
Description
#14 x 2.5" wood screw
Alligator
®
anchor
