PeerlessBoilers PBC-40 - Page 38

Status
(2000)
Parameters
Parameter Function
Unit/Value
Default
Options
2025
Warm Weather Shutdown Temperature
–
Outdoor temperature that will block all CH demands until temperature falls below this value
°F 72
2026
Boost Function: Increment
–
Calculated Setpoint increase after boost delay time period is met
–
Boost will continually increase setpoint every boost time period until demand is met or
Maximum CH Setpoint design limit is reached.
°F 5
2027
Boost Function: Delay
–
Time delay before boost function activates during a single demand
Minutes 20
2028
CH Night Setback Temperature
–
Calculated CH Setpoint setback value when the Night Setback Function is activated
°F 10
2035
DHW mode
# 5
2036
NON FUNCTIONAL
2037
NON FUNCTIONAL
2038
NON FUNCTIONAL
2042
Domestic Hot Water Priority
–
Does not function for Series PBC™ Applications
0/1/2/3 2
2043
Domestic Hot Water Priority Time
–
Does not function in Series PBC™ Applications
Minutes 60
2044
DHW Post Purge- Circulator
Seconds 10
2048
DHW Setpoint
°F 122
2064
Preheat Mode
–
0: OFF
–
1: Anti Frost
–
plate heat exchanger is kept above 41°F
–
2: Eco Mode
–
plate heat exchanger is kept above 86°F for faster response at expense of
fuel utilization.
–
3: Comfort Mode
–
plate heat exchanger is kept at DHW for fastest response at greatest
expense to fuel utilization
# 1
2091
Maximum DHW Setpoint °F 176
2096
Minimum DHW Setpoint °F
2109
CH Calculated Setpoint Offset
–
Allows the manual adjustment of the Calculated CH Setpoint by this value
°F 0
2110
Minimum CH Setpoint °F 68
2111
Maximum CH Setpoint °F 190
2112
CH Hysteresis Down °F 9
2113
Maximum DHW Power
–
Limits the maximum available input to the boiler to satisfy DHW demands
% 100
2114
Minimum DHW Power
–
Limits the minimum available input to the boiler to satisfy DHW demands
% 1
2115
NON FUNCTIONAL
2124
-FACTORY SET. DO NOT CHANGE
-WARNING: CHANGING THESE SETTINGS
WILL CAUSE BOILER TO NOT OPERATE
PROPERLY
# 0
2125
# 2
2126
# 9
2127
# 0
2128
# 0
2129
# 0
2130
Flow Scaling Factor
–
NON FUNCTIONAL
2131
Minimum CH Loop Pressure
–
Pressure at Boiler will shut down after “FILL” warning will appears
PSI 10.2
36
BOILER CONTROL: INTERNAL WIRING & OPERATION
Table 8.7 (cont.): Installer Menus (2000 Level)
