G. INSTALLER MENU – 2000 LEVEL
The Installer Menu is accessible by inputting the proper
PIN number into screen CODE of the User Menu. When
CODE is the parameter selected press the M button. Use
the R1 and R2 buttons to select the proper number for
the flashing place in the PIN. Pressing M will advanced to
the next digit. If an incorrect number is selected, it is
required to cycle through all four places with the M button
to return and correct the number.
Once the 4 digit passcode has been entered, press L1 or
L2 until the menu selection screen is shown. Press R1 or
R2 until 2000 is shown in the small digits. Press M to
enter the Installer Menu
35
Table 8.7: Installer Menus (2000 Level)
Status
(2000)
Parameters
Parameter Function
Unit/Value
Default
Options
2001
Central Heat Mode
# 1
2003
CH Setpoint
°F 160
2005
CH Post Purge
–
Circulator
Seconds 10
2007
CH Hysteresis UP
–
Controls Boiler shutoff point above Setpoint
°F 9
2009
Anti-cycling period
–
Delay period during which boiler will not fire the burner if a supply temperature of CH
Setpoint + CH Hysteresis is reached during a single demand period.
Seconds 180
2010
Anti-cycling Differential
–
Supply temperature drop below CH setpoint that must be reached before the burner will fire
if a supply temperature of CH Setpoint + CH Hysteresis is reached during a single demand
period.
–
Overrides Anti-Cycling Period
°F 16
2014
Maximum CH Power
–
Limits maximum CH input available to the control to satisfy a demand
–
Default values should not be changed
%
PBC-34™: 57
PBC-40™: 61
PBC-52™: 54
2015
Minimum CH Power
–
Limits the minimum power available to the boiler to satisfy a demand
% 1
2019
Boiler Supply Design Temperature
–
Sets the reset curve design temperature that will be targeted when the outdoor temperature
is at the chosen outdoor design temperature.
–
For default: Boiler will target 190°F when the outdoor temperature is 23°F or lower.
°F 190
2020
Outdoor Design Temperature
–
Sets the Outdoor Temperature at which the boiler will target the Boiler Supply Design
Temperature.
–
For default: Boiler will target 190°F when the outdoor temperature is 23°F or lower.
°F 23
2021
Boiler Mild Weather Temperature
–
Sets the reset curve design temperature that will be targeted when the outdoor temperature
is at the Outdoor Mild Weather temperature.
–
For default: Boiler will target 104°F when the outdoor temperature is 68°F.
°F 104
2022
Mild Weather Design Outdoor Temperature
–
Sets the Outdoor Temperature at which the boiler will target the Boiler Mild Weather Design
Temperature.
–
For default: Boiler will target 104°F when the outdoor temperature is 68°F.
°F 68
2023
Maximum CH Setpoint
–
Design Supply Maximum (limit)
–
Sets upper limit of Calculated CH setpoint
–
Calculated CH setpoint will always be at or below this value
°F 68
2024
Minimum CH Setpoint
–
Design Supply minimum (limit)
–
Sets lower limit of Calculated CH setpoint
–
Calculated CH setpoint will always be at or above this value
°F 190
BOILER CONTROL: INTERNAL WIRING & OPERATION
Installer Code is 0231
