IPPSB-DB Mainboard User Guide 17
Connectors Connectors
IR connector (A25/Pitch 1.25mm)
Pin Signal Name Pin Signal Name Pin Signal Name
1 RX_NR# 3 +5VSB 5 GND
2 GND 4 GND
