IPPSB-DB Mainboard User Guide
Components
Mainboard Layout
*These components do not have pin denitions shown in this document.
No. Name No. Name No. Name
A1
2.5” HDD
connector
A13
Webcam+DMIC
connector
A26
TV tuner slot
A2
ODD Power
connector
A14*
Mini PCI-E slot
(x16)
A27*
USB 2.0 ports
A3
SATA HDD
Power
connector
A16
Wireless slot
A28
Low Pin Count
connector
(for Debug Card)
A4
SATA connector
A17*
Memory
sockets
A29
Intel
Management
Engine selector
A5
CPU fan2
connector
A18
LCD mode
switch/HD LED/
Brightness
control connector
A30*
VGA In port
A6
System fan
connector
A19
Card reader
A31*
Intel Platform
Controller Hub
A7
Panel inverter
connector
A20
Clear CMOS
selector
A32*
Line_out port
(convertible to
HDMI Out port)
A8*
Battery
A21*
USB 2.0 ports
(convertible to
USB 3.0 ports)
A33
SATA connector
A9
LVDS connector
A22*
Audio jacks
A34*
LAN (RJ-45)
port
A10
Power button/
Power LED/
Volume control
connector
A23
Speaker
connector
A35*
ATX power port
A11*
Intel Socket 1155
CPU Socket
A24
RF connector
A12
EDID
connector
A25
IR connector
