IPPSB-DB Mainboard User Guide 7
Selectors
Settings:
[2-3] Normal [1-2] Flash override
Intel Management Engine selector (A29/Pitch 2.54mm)
Pin Signal Name Pin Signal Name
1 HDA_SDO 3 NC
2 +3P3VSB
Settings:
[1-2] Normal [2-3] Clear CMOS
Clear CMOS selector (A20/Pitch 2.54mm)
Pin Signal Name Pin Signal Name
1 N/C 3 GND
2 RTC_RST#
