Pegatron IPPSB-DB - Low Pin Count Connector (Debug Card)

IPPSB-DB Mainboard User Guide 19
Connectors Connectors
Low Pin Count connector (for Debug Card) (A28/Pitch 0.5mm)
Pin Signal Name Pin Signal Name Pin Signal Name
1 +3P3VSB 5 NC 9 GND
2 LAD0 6 LAD2 10 LFRAME#
3 +3P3VSB 7 NC 11 GND
4 LAD1 8 LAD3 12 CK_33M_DEBUG
