Pegatron M2N-VM/S 1-25
7. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports
are available for connecting USB 2.0 devices.
8. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports
are available for connecting USB 2.0 devices.
9.
Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor
or other VGA-compatible devices.
10. Serial port (COM1).
This port connects a modem, or other devices that
conform with serial specication.
11. PS/2
keyboard port (purple). This port is for a PS/2 keyboard.
Audio 2, 4, or 6-channel conguration
Port Headset
2-speaker
4-speaker 6-speaker
Light Blue Line In Surround Out Surround Out
Lime Line Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Center/Bass
