Pegatron M2N-VM/S 2-23
The following item appears when the Memclock Mode item is set to [Limit] or
[Manual].
Memclock Value [400 MHz]
Sets the memory clock mode limit. Conguration options: [400 MHz] [533 MHz] [ 667
MHz] [ 800 MHz]
CAS Latency (CL) [Auto]
Sets the CAS Latency (CL) mode. Conguration options: [Auto] [3.0] [4.0]
[5.0] [6.0]
TRCD [Auto]
Sets the TRCD mode. Conguration options: [Auto] [3 CLK] [4 CLK] [5 CLK]
[6 CLK]
TRP [Auto]
Sets the TRP mode. Conguration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6
CLK]
TRAS [Auto]
Sets the TRAS mode. Conguration options: [Auto] [5 CLK] [6 CLK] ~ [18
CLK]
Command Timing (2T mode) [Auto]
Sets the Command Timing (2T mode).Conguration options: [Auto] [1T] [2T]
MCT Timing Mode [Auto]
Sets the MCT Timing Mode.Conguration options: [Auto] [Manual]
Bank Interleaving [Disabled]
Allows you to enable the bank memory interleaving.
Conguration options: [Disabled] [Auto]
Enable Clock to All DIMMs [Disabled
Enables or disables clock to all DIMMs.
Conguration options: [Disabled] [Enabled]
MemClk Tristate C3/ALTVID [Disabled]
Enables or disables the MemClk Tristate C3/ALTVID.
Conguration options: [Disabled] [Enabled]
Memory Hole Remapping [Enabled]
Enables or disables the memory remapping around memory hole.
Conguration options: [Disabled] [Enabled]
