Pego ECP200 BASE 2 - Technical Characteristics

ECP200 BASE 2/4
Page 7
USE AND MAINTENANCE MANUAL
Rev. 02-09
TECHNICAL CHARACTERISTICS
Power supply
Voltage
230 V~ ± 10% 50Hz / 60Hz
Max power (only electronics) ~ 7 VA
Rated current
(With all loads connected)
16A
Climatic conditions
Working temperature -5 ÷ +50°C
Storage temperature -10 ÷ +70°C
Relative ambient humidity Lower than 90% Hr
General characteristics
Type of sensors that can be connected NTC 10K 1%
Resolution 0,1 °C.
Sensor read precision ± 0,5 °C
Read range -45 ÷ +45 °C
Output characteristics (free voltage contact)
Description Installed relay Card output characteristics BASE 2 BASE4
Compressor
(Relay 30A AC1)
10A 250V
~ (AC3) (2HP)
(100000 cycles)
X X
Elements
(Relay 30A AC1)
16A 250V
~ (AC1)
X
Fans
(Relay 16A AC1)
2,7A 250V
~ (AC3)
X
Room light
(Relay 16A AC1)
16A 250V
~ (AC1)
X X
Alarm / Aux (Optional) (Relay 8A AC1)
8(3)A 250V
~
X
optional
X
optional
Dimensional characteristics
Dimensions 19.3cm x 7.9cm x 20.3cm (HxPxL)
Dimensions
Box protection rating IP65
Box material ABS autoestinguente
Type of insulation Class II
CHAP. 3 - Technical characteristics
CHAPTER 3: TECHNICAL CHARACTERISTICS
3.1
