Pella 6000 - Storm Door Frame Mounting; Attaching Door Frame to Entryway; Securing Jamb and Removing Support Block

Raise Up, Slide Over,
then Lower
Right
Hinge
Illustrated
Continued from
Page 4
5
RIGHT HINGE
Doors Only
SLIDE To This Side
LEFT HINGE
Doors Only
SLIDE To This Side
11
Set door in opening
(resting on boom spacer from step 10).
Hold tight to hinge side.
“Mounting Frame Screw Bag”
unpainted
#6 x 1” Pan Head
Qty.
5
Drill 3/32”
Pilot Holes
12
Predrill the five hinge
side hole locations.
Secure with screws.
Open the door.
Predrill the eight holes.
Secure with screws.
“Jamb Screw Bag”
unpainted
#8 x 3/4” Pan Head
Qty.
8
Drill 3/32”
Pilot Holes
13
Continued on Page 6
O
p
e
n
Left Hinge
Illustration
Remove and discard
installation support
block.
14
Remove
and
Discard
Left Hinge
Illustration
Right
Hinge
Illustrated
Installation
Support Block
