PV 20a
3 BURN AIR @14kW Fan speed at power level 3 rps 27 25 29
4 BURN AIR @16kW Fan speed at power level 4 rps 30 28 32
5 BURN AIR @18kW Fan speed at power level 5 rps 34 32 36
6 BURN AIR @20kW Fan speed at power level 6 rps 38 36 40
7 TESTING AIR Fan speed for testing rps 42 38 50
8 IGNITION AIR Fan speed during ignition cycle rps 25 20 35
9 BURN END AIR Fan speed durinf end blow cycle rps 20 10 30
10 HOLD FLAME AIR Fan speed during hold flame cycle rps 10 7 14
11 HOLD FLAME ON In case of Hold flame is set on AUTO,
flame holding activated after 2 waiting
session, both less then 15 min.
min 15 5 30
12 HOLD FLAME OFF In case of Hold flame is set on AUTO,
there is maximum time for flame
holding cycle.
min 60 30 90
13 MIN POWER Minimum power level kW 12 10 20
14 MAX POWER Maximum power level kW 18 10 20
15 AUTO POWER UP min 60 30 120
16 AUTO POWER
DOWN
min 30 15 45
21 PELLET NORMAL Internal feeder production g/rot 33 28 38
22 PELLET LIGHT Internal feeder production g/rot 31 28 38
23 PELLET HEAVY Internal feeder production g/rot 35 28 38
24 LOADING FEED Feeder turns during loading cycle rot 21 20 24
25 LOADING 2 FEED Feeder turns during second loading
cycle
rot 3 1 8
26 BURN END FEED rot 15 10 20
30 SMOKEFAN ON 0- OFF, 1 - ON 0/1 0 0 1
31 SMOKEFAN 1 Smokegas fan speed for ignition, end
blow, burn at power level 1 and 2
% 40 0 100
32 SMOKEFAN 2 Smokegas fan speed for burn at power
level 3 and 4
% 60 0 100
33 SMOKEFAN 3 Smokegas fan speed for burn at power
level 5 and 6
% 80 0 100
40 PHOTOCELL Photocell sensitivity % 84 50 100
41 PREBURN TIME Preburn cycle lenght s 50 30 100
42 PREBURN CYCLES n 2 1 4
43 OVERHEAT TEMP Maximum allowed burner
temperature
°C
50 20 70
50 ON ERROR RELAY Error output relay contacts (ON - NO
or OFF -NC)
ON ON/OFF
99 MODEL VERSION Load default settings for chosen
burner model or change model type
0 20a 20a/30a/50a/
100a
Refilling fuel
The fuel storage must be refilled before it runs empty. Fuel can be added at any time during the
operation. To add fuel, simply pour a new bag of pellets into your fuel storage.
18 www.pelltech.eu
