Table 1.5 – Dilution Tunnel and Flue Gas Measurements
Segment
Average
Flue Draft
(in H
2
O)
Average Dilution Tunnel Gas Measurements
Velocity
(ft/sec)
Flow Rate
(dscf/min)
Temperature
(°F)
Integrated Total
-0.034
14.69
167.4
84
Table 1.6 – Heater Configuration
Segment
Heat Setting
(Control
Knob)
Trim Setting
Power Level
(Shown in
Program)
Pretest
Hi
+4
5
Maximum
Hi
+4
5
Medium
3
+3
2
Minimum
Lo
0
1
