Introduction
While this counter has a vast array of features
and operating modes, the majority of the most
useful functions can be learned in just a few
minutes. The following descriptions and exer
-
cises will help you grasp the basics of opera
-
tion. They will also serve as an introduction to
some of the more advanced features. It will
take you about half an hour to gather experi
-
ence enough to continue exploring the world
of counting on your own.
User Interface
The fundamental idea has been to facilitate
even complex measurements by a consistent
interactive user interface that fully exploits the
large graphic display. The casual as well as
the frequent user will benefit from a combina
-
tion of hard and soft keys. In this context hard
keys either act immediately or open fixed
menus, whereas the function of soft keys de
-
pends on the display information.
Getting Familiar with
the Counter
The front panel is laid out in a logical fashion.
Take a few seconds to find the sections de-
scribed below on the front panel of your coun-
ter. See also the figure on this page. It will
help you locate the different keys faster.
Operating the Counter
3-2 Introduction
TRIG
GATE
TRIG
pendulum
TIMER / COUNTER / ANALYZE R
100ps / 300MHz
CNT-90
INPUTINPUT
INPUT A
SETTINGSETTING
SETTINGS
MATH/LIM USER OPUSER OP
USER OPT
HOLD / RU
HOLD / RUN
RESTARTINPUTINPUT
INPUT B
A
300 MHz
B
MAX
12Vrms 50
30Vrms 1M
!
C
MAX +30dBm
50
0.2 8GHz
!
Move CursorSave&Exit Don't Save&ExitPower
Hard Menu Keys
Freeze
Select Function Autoset/Preset Enter
Presentation Modes
Soft Keys
To Next Page
