Pendulum CNT-90 - Frequency Ratio F 1 2; Phase; Duty Factor

Specifications
Phase A Rel. B, B Rel. A
Range:
-180° to +360°
Resolution:
0.001° to 10 kHz 0.01° to
1 MHz 0.1° to 10 MHz 1°
>10 MHz Resolution can
be improved by averaging
(Statistics)
Input Frequency:
Up to 160 MHz
Min. Pulse Width:
1.6 ns
■ Display:
Main Parameter:
Phase
Aux. Parameters:
Freq (prim. channel),
V
A/VB (in dB)
Duty Factor A, B
Range:
0.000001 to 0.999999
Input Frequency:
0.1 Hz - 200 MHz
Min. Pulse Width:
2.5 ns
Modes:
Pos. or neg. duty factor
■ Display:
Main Parameter:
Duty factor
Aux. Parameters:
Period, pulse width
Vmax, Vmin, Vp-p A, B
Alternative data within parentheses refer to
input attenuator setting x10.
Range:
-5 V to +5 V (-50 V to +50 V)
Input Frequency:
DC, 1Hz - 300 MHz,
100 Hz - 300 MHz default
(higher LF limit means higher
meas. speed)
Mode:
V
max
, V
min
, V
p-p*
Resolution:
3 (30) mV
Accuracy (typ.)*:
DC
1% ± 15 (150) mV
1 H z - 1 k H z
1% ± 15 (150) mV
1 kHz - 20 MHz
3% ± 15 (150) mV
20 - 100 MHz
10% ± 15 (150) mV
100 - 300 MHz
30% ± 15 (150) mV
* V p-p is calculated as Vmax - V min, which
means that the maximum absolute error will
be ±30 (300) mV.
■ Display:
Main Parameter:
Vmax or Vmin or Vp-p
Aux Parameters:
V
min
, V
p-p
or
V
max, V p-p or
V
min
,
V max
8-5
