Specifications
Pulse Output
Mode:
Period:
Pulse Width:
Output Level:
Connectors:
Pulse Out, Gate Open, Alarm
Out
20 ns - 2 s in 10 ns incr.
10 ns - 2 s in 10 ns incr TTL
levels in 50
Ω
, 2 n s
rise
time
BNC (SMA for Input C)
Auxiliary Functions
Trigger Hold-Off
Time Delay
Range:
20 ns - 2 s, 10 ns resol.
External Start/Stop Arming
Modes:
Start arming, stop arming, start
and stop arming
Input Channels:
A, B, E (EXT ARM)
Max. Rep. Rate
for Arming Signal
Channel A, B:
160 MHz
Channel E:
80 MHz
Start Time Delay
Range:
10 ns - 2 s, 10 ns resol.
Stop Time Delay*
20 ns - 2 s, 10 ns resol.
Range:
* Stop Time Delay can only be used in
conjunction with the non-manual Totalize
Functions.
Statistics
Functions:
Maximum, minimum, mean,
Δ
max-min
, standard deviation,
Allan deviation
Display:
Numeric or numeric +
Graphic:
Sample Size:
Max. Sample
Rate:
graphic
Histogram & trend plot, auto
scaled
2 to 2*10
9
250 kSa/s measured, 2 kSa/s
calculated, depending on
meas. function and graphics
