Capacitors inside the instrument can hold
their charge even if the instrument has
For bench-top use, a fold-down support is
been separated from all voltage sources.
available for use underneath the counter. This
support can also be used as a handle to carry
the instrument.
Fig. 1-2 Fold-down support for comfortable
Fitting the rack mount brackets on the
Dimensions for rackmounting hardware.
If you have ordered a 19-inch rack-mount kit
for your instrument, it has to be assembled after
delivery of the instrument. The rackmount kit
consists of the following:
— 2 brackets, (short, left; long, right)
— 4 screws, M5 x 8
— 4 screws, M6 x 8
WARNING: Do not perform any internal
service or adjustment of this instrument
unless you are qualified to do so
Before you remove the cover, disconnect
mains cord and wait for one minute.
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
