Specifications
Agilent
HP 53131/132/181 com-
Compatibility:
mands are emulated. Code
and response format is
compatible. No timing
compatibility. No resolution
compatibility
Interface Func-
SH1, AH1, T6, L4, SR1,
RL1, DC1, DT1, E2
tions:
Max. Meas. Rate
Via GPIB:
2000 readings/s (block)
350 readings/s (individual)
To Internal
Memory:
250 k readings/s
Internal
Memory
Size:
Up to 750 k readings
Data Output:
ASCII, IEEE double precision
floating point
USB Interface
Version:
2.0, 12 Mb/s
Protocol:
USBTMC-USB488
TimeView™
This software package is intended for ad-
vanced Modulation Domain analysis and
runs on any 32-bit Windows® system.
■ Data Capture Modes &
Measurement Rate
Effective rate depends on measurement
function and internal data format.
Free-running
Measurement:
250 k readings/s
Repetitive
Sampling:
Up to 100 Msa/s equiv. sample
rate (10 ns between samples)
Continuous
Yes, from LF to 250 kHz
Single Period:
repetition rate
Waveform
Capture:
Yes
Data Analysis
Measurement data vs time
Features:
Cursor measurements
Distribution histogram
FFT graph w. Hamming,
Hanning and other relevant
filters
Smoothing
Zoom
Setup, measurement data
archive and printing
Zero dead time ADEV and
MADEV vs.

Battery Unit
Option 23/90
Battery Type:
Li-Ion, 22.2 V, 90 Wh
Ext. DC Input:
12 to 18 V, max 6 A
Connector:
XLR male, 3-pin
Oper. & Charg.
Temp. Range:
0 to +40 °C
Storage:
-20 to +60 °C (1 month)
-20 to +45 °C (3 months)
-20 to +20 °C (1 year)
Operating Time
(@ +25 °C):
ON: >4.5 h
Stby: >24 h
Charging:
Automatic, when ext. AC or
DC is connected
Charging Time
(@ +25 °C):
<8.5 h
Status Indicator:
On-screen w. low battery
warning
Weight:
1.2 kg
