Specifications
Period A, B Single
Range A, B:
3.3 ns - 1000 s
Resolution:
50 ps rms typical
■ Display:
Main Parameter:
Period
Aux. Parameters:
V max,
V
p-p
V min,
Period A, B Back-to-Back
Range A, B:
4

s - 1000 s
Resolution:
50 ps rms typical
■ Display:
Main Parameter:
Period
Aux. Parameters:
V max, V min, V p-p
Ratio A/B, B/A, C/A, C/B
to determine sign (A before
B or A after B)
■ Display:
Main Parameter:
Time interval
Aux. Parameters:
None
Pulse Width A, B
Range:
2.5 ns - 10
6
s Up to
Input Frequency:
200 MHz Pos.
Modes:
pulse width or neg.
pulse width
■ Display:
Main Parameter:
Pulse width
Aux. Parameters:
V
max
,
V min,
V
p-p
Rise and Fall Time A, B
Range:
Freq Range A,B:
Freq Range C:
■ Display:
Main Parameter:
Aux. Parameters:
10
-9
to 10
11
(one-pass
measurem., values < 1
with reduced resolution)
0.1 Hz to 400 MHz
100 MHz to 3 GHz
Ratio
Freq 1, Freq 2
Time Interval A to B, B to A, A
t o A , B t o B
Range:
Input Frequency:
Trigger Levels:
Min. Pulse Width:
Modes:
Min. Amplitude
■ Display:
Main Parameter:
Aux. Parameters:
6
1.5 ns - 10 s
Up to 160 MHz (square
wave)
Default 10% and 90%
Manually adjustable
1.6 ns
Rise or fall time
100 mVp-p
Rise or fall time
Slew rate, V
max, V min
Range (normal
calculation):
Range (smart
calculation):
Resolution Single
Shot:
Input Frequency:
Min. Pulse Width:
Smart Calculation:
0 ns to +10
6
s
-10
6
to +10
6
s
50 ps rms typical
Up to 160 MHz
1.6 ns
Smart Time Int. w. 4 time
stamps (2 consecutive Trig
A plus 2 consecutive Trig B)
