1020 Mono Filler
16
The time the controller waits before determine the end value.
The H-time works together with the stability parameter.
Δ Not used if Stability parameter is set to Stable
Kinetic Energy Blind time is the time in which the kinetic
energy disappears after coarse dosing turns off. The indicator
value will not be read out by the program during this time.
Δ K.E.B. time must be less than the remaining Fine Time
correction
The amount of product that falls on/into the weigher after
dosing is stopped. The correction value indicates the strength
of the correction. 0% means fixed inflight.
inflight
The inflight correction is not able to correct more than the
maximum inflight. If the calculated inflight is 0, the inflight will
This correction will automatically correct the turnover value
to reach the needed Fine Time. 0% means fixed turnover.
This is the ideal fine time to reach a fast dosing cycle.
Δ The remaining fine time must be more than the K.E.B. time
This checks if the dosed weight is within the tolerance. If the
dosed weight is under the setpoint - min. tolerance, the fine
output will turn on until the weight is correct. If the dosed
weight is over the setpoint + max. tolerance, an alarm is given
until it‘s accepted by input 2. The minimum and maximum
tolerance can be set in the recipe.
interval
The interval time of the fine output (On/Off) in case of a low
tolerance. If the tolerance interval is 0, the fine output is on
until the correct weight is reached.
After the dosing is finished, the display hold time starts. The
dosed value will be frozen for this time. When a new dosing
starts before the display hold time is elapsed, the hold time
Select if a release valve is used in the installation.
• Yes => output 4 is used to activate the release valve
•
No => output 4 is used to activate the indicator alarm
The value under which the weigher is seen as empty after
release.
Δ Not used if no release valve is selected
