System 450™ Series Control Modules with Analog Outputs Installation Instructions
9
Accessing the System 450 Setup Start Screens
Access the System 450 Setup Start screens from the Main screen. See Table 3 for more information about the
Setup Start screens.
To access the System 450 setup screens:
1. Power on the module assembly. After the Startup screen appears briefly (displaying the control module
firmware version), the Main screen appears on the LCD.
2. With the Main screen displayed, press any key to exit idle mode, then press and hold
and simultaneously
for 5 seconds to access the setup screens and go to the Sensor Setup Start screen.
3. Press
repeatedly to scroll through the Output Setup Start screens. See Figure 6.
Note: The UI returns to the Main screens after 2 minutes of inactivity in any screen in the UI.
Setting Up System 450 Sensors
You must set up the input sensors for your control system before you can set up any outputs. To set up the input
sensors you must access the setup screens.
The Sensor Setup Start screen is the first screen displayed when you access the system setup screens.
Table 4 provides information about System 450 sensors, Sensor Types, parameter values, and specified sensor or
transducer product code numbers. Table 5 provides sensor setup information, procedures, and example screens.
Figure 6 on page 26 provides a System 450 UI setup example.
Table 4: System 450 Sensor Types, Setup Values, and Sensor or Transducer Product Codes (Part 1 of 2)
Sensor
Type
Unit of Measurement
Code
(Condition/Units)
Effective
Sensing
Range
Range of
Usable
Values
1
Resolution
Increment
Value
Minimum
Proportional
or Control
Band
Sensor Product
Type Number
2
F F (Temperature/degrees) -46 to 255 -40 to 250 1 1 A99x-xxx
C C (Temperature/degrees) -43 to 124 -40 to 121 0.5 0.5 A99x-xxx
rH % (Humidity/%RH) 1 to 100 10 to 95 1 2 HE-67Sx-xxxxx
HE-67Nx-xxxxx
HE-68Nx-0N00WS
P 0.25 INWC (Pressure/in. W.C.) -0.250 to
0.250
-0.225 to
0.250
0.005 0.01 DPT2650-R25B-AB
P 0.5 INWC (Pressure/in. W.C.) 0 to 0.5 0.025 to 0.5 0.005 0.01 DPT2650-0R5D-AB
P 2.5 INWC (Pressure/in. W.C.) 0 to 2.5 0.1 to 2.5 0.02 0.1 DPT2650-2R5D-AB
P 5 INWC (Pressure/in. W.C.) 0 to 5.0 0.25 to 5.0 0.05 0.25 DPT2650-005D-AB
P 8 bAR (Pressure/bar) -1 to 8 -1 to 8 0.05 0.1 P499RCP-401C
P598RCPSN401C
P 10 INWC (Pressure/in. W.C.) 0 to 10 0.5 to 10 0.05 0.2 DPT2650-10D-AB
P 15 bAR (Pressure/bar) -1 to 15 -1 to 15 0.1 0.2 P499RCP-402C
P598RCPSN402C
P 30 bAR (Pressure/bar) 0 to 30 0 to 30 0.1 0.4 P499RCP-404C
P598RCPSN404C
P 50 bAR (Pressure/bar) 0 to 50 0 to 50 0.2 0.4 P499RCP-405C
P598RCPSN405C
M
