15
3. Monitor the water temperature by watching the Fill /Shower Water
Temperature Readout (see Figure 1) and check the water temperature
by allowing it to run over your wrist. Adjust the water temperature by
turning the Temperature Control Knob to a normal bathing
temperature, 95 to 105 degrees Fahrenheit.
WARNING
Failure to monitor the temperature readout and check the water
temperature by allowing it to run over your wrist, could result in a
hot-water burn to the resident or the operator Do not touch water
over 110°.
4. When filled, press the Fill Button (see Figure 1) again to stop the
water flow.
Using Cascade™ Tub with Reservoir
See Figure 3 for locations of the controls listed in this section.
1. Press the reservoir fill ON button to begin filling the reservoir.
2. Monitor the reservoir water temperature by watching the temperature
readout located on the reservoir. To adjust the temperature of water
flowing into the reservoir, turn the mixing valve handle (see
Figure 1) to a normal bathing temperature, 95-105 degrees
Fahrenheit as shown on the fill/shower temperature read-out (see
Figure 1).
3. The reservoir can hold up to 48 gallons of water and can be stopped at
anytime during the filling process if you desire. To stop the filling of the
reservoir, simply push the reservoir fill OFF button located on the
reservoir.
4. If you do not stop the filling of the reservoir by using the reservoir fill
OFF button, the filling of the reservoir will stop filling
AUTOMATICALLY once it is full.
