CLEAN AND CLEAR
®
PLUS Cartridge Filter Installation and User’s Guide
Clean and Clear
®
Plus Cartridge Filter Parts List
Replacement Parts
Item
No.
Part
No.
Description
1 190058 Pressure Gauge, with Indicator
2 98209800
High Flow Manual Air Relief Valve
(HFMARV)
3 178616 Compression Spring
4 170026 Top Manifold, 240 C&C Plus
4 170027 Top Manifold, 320/420/520 C&C Plus
5 R173572 Cartridge Element, 240 C&C Plus, 4 req.
5 R174573 Cartridge Element, 320 C&C Plus, 4 req.
5 R173576 Cartridge Element, 420 C&C Plus, 4 req.
5 R173578 Cartridge element, 520 C&C Plus, 4 req.
6 170030 Air Bleed Tube Assy., 240 C&C Plus
6 170029 Air Bleed Tube Assy., 320 C&C Plus
6 170028 Air Bleed Tube Assy., 420 C&C Plus
6 178583 Air Bleed Tube Assy., 520 C&C Plus
7 170040 Bottom Manifold
8 39010200 O-ring, Tank Clamp (.470 O.D.)
9 190003 Clamp Band Replacement Kit
10 195610 Clamp Washer, Small I.D.
11 195611 Clamp Washer, Large I.D.
12 194997 Clamp Nut
13 195612 Clamp Spring, 4-Coil
14 190039 Baffle Assy., C&C Plus
15 98960311 Union Kit, Black
15 271096
2" Valve Adapter Kit, 1 ½ in. x 2 in. (set),
White
15 270004
2" Valve Adapter Kit, 1 ½ in. x 2 in. (set),
Black
15 274426Z 2 x 2.5" Valve Adapter Kit,
Item
No.
Part
No.
Description
16 170036 Pipe Assy. Outlet, C&C Plus
17 190143 O-ring, Drain
18 190030 Drain Plug, without O-Ring
19 170023 Tank, Lid Assy., 240 C&C Plus
19 170024 Tank, Lid Assy., 320 C&C Plus
19 178581 Tank, Lid Assy., 420 C&C Plus
19 178582 Tank, Lid Assy., 520 C&C Plus
20 178578
Tank, Bottom Assy. (Includes Items 7, 14,
16 and 18)
21 86006900 O-ring
22 195339 Ring, Steel Back-up
- 192019 Drain Plug Wrench
- 171013 Label Kit w/ Air Relief, 240 C&C Plus
- 171014
Label Kit w/ Air Relief, 320/420/520 C&C
Plus
- 190106Z Air Bleed Screen Cap
(-) Not Shown

Pentair CLEAN AND CLEAR PLUS Specifications

General

Filter Type	Cartridge
Flow Rate	150 GPM
Cartridge Quantity	4
Max Pressure	50 psi
Material	Fiberglass-reinforced composite
Inlet/Outlet Size	2 inches
Cartridge Material	Polyester
Filter Area	Varies by model (see product documentation)
Dimensions	Varies by model (see product documentation)
Weight	Varies by model (see product documentation)
