INTELLIBRITE
®
5G Pool and Spa Lights Installation and User’s Guide
For countries in compliance with International Electromechnical
Commission (IEC) regulatory standards: The light fixture must
be installed by a licensed or certified electrician or a qualified pool service person, in
accordance with IEC 364-7-702 and all applicable local codes and ordinance. Improper
installation will create an electrical hazard, which could result in death or serious injury
to pool user, installer or other due to electrical shock and may also cause damage to the
property.
iii
IMPORTANT WARNING AND SAFETY INSTRUCTIONS
RISK OF ELECTRIC SHOCK AND INJURY. USE ONLY THE
(*) Note: Wet-niche luminaires complying with requirements for both uses may bare
both the Listed Wet-Niche Submersible Luminaires UL Mark. A luminaire not bearing the
corresponding UL Listing Mark is not considered by UL to have been produced under UL’s
Listing and Follow-Up Service for the associated usage location.
CAUTION - The IntelliBrite
®
5G Light fixture must only be used with Pentair Water Pool
and Spa fixture housings (niches). If the IntelliBrite light fixture is installed into other
niches, the installation will not carry U.L. approval and will void all warranties.
Salt is an inherently corrosive material. While the levels of salt required
for proper operation of an electronic chlorine generator are relatively low
when compared to sea water and other salt solutions, placing any amount of salt in your
pool increases the likelihood of corrosion or other deterioration of pool equipment and any
surfaces used in and around your pool. Metal parts and certain natural and man-made
surfaces are particularly susceptible to corrosion and deterioration when used in and
around salt water pools. Pentair does not represent or otherwise guarantee that the proper
use of an electronic chlorine generator will prevent corrosion or other deterioration of pool
equipment and any surfaces used in and around your pool. Consult your experienced
pool professional, who should be able to advise you on the proper material selection,
installation techniques for those materials, and the proper use, care and maintenance of
those materials for your specific pool type and location in order to minimize the corrosion
and deterioration that is inherent in and around salt water pools.
INSTALLATION METHOD SPECIFIED BELOW.
NOTICE: The external flexible cable or cord of this luminaire cannot be replaced; if
the cord is damaged, the luminaire shall be destroyed.
- REPLACE ANY CRACKED PROTECTIVE SHIELD (CRACKED LENS) WITH NEW
LENS AND GASKET. FOR MORE INFORMATION SEE PAGE 11.
- FOR LIGHT OPERATION, ONLY USE A SAFETY ISOLATION TRANSFORMER.
POOL AND SPA FIXED LUMINARIES: Follow these guidelines when installing,
replacing or repairing Pentair Aquatic Systems Pool and Spa fixed luminaries:
Location of Pentair Water Pool and Spa Fountain Required Installation Method
Luminaire Use Fixture* (P/N 560001 and P/N 560000)
Swimming Pool Wet-Niche Swimming Pool Fixture Housing (Forming Shell) ONLY.
and Spa (or Spa) Luminaire (Light) DO NOT USE Fountain Fixture Stand.
Fountain Wet-Niche Submersible Luminaire (Light) Fixture Housing (Forming Shell) or
swimming Pool (or Spa) Luminair (Light) Fountain Fixture Stand
CAUTION! Luminaires not suitable for direct mounting
on normally flammable surfaces (suitable ONLY for
mounting on non-combustible surfaces.
Surface Mount
Fixed pool and spa luminaries specification:
12 VAC 50/60 Hz - 120VAC ,50/60 Hz.
To Next Page
