INTELLIBRITE
®
5G Pool and Spa Lights Installation and User’s Guide
INTELLIBRITE
®
5G Pool and Spa Lights Installation and User’s Guide
Replacing the IntelliBrite
®
5G Spa Light Face ring and
Gasket (P/N 640045) or Gasket and Lens (640046) see page 21
1. Turn off main electrical switch or circuit breaker, as well as the switch
which operates the IntelliBrite underwater light itself.
2. REMOVING THE INTELLIBRITE SPA LIGHT: Remove the pilot screw at top
of face ring, remove the light assembly from the niche. Place the assembly
on the deck. Note: It is not necessary to drain down the pool.
Be sure to keep the pilot screw from the IntelliBrite light.
This screw mounts and electrically grounds the housing securely to
the mounting ring and wet niche. Failure to use the screw provided could create an
electrical hazard which could result in death or serious injury to pool users, installers
or others due to electrical shock.
D A N G E R !
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION
Always disconnect power to the pool light at the circuit breaker
before servicing the light. Failure to do so could result in death
or serious injury to installer, pool professional, pool users, or
others due to electrical shock.
Note: When replacing an IntelliBrite 5G Spa light assembly, a new
spa light assembly includes a light engine, lens, gasket and face ring
(for part light assembly part numbers, see page 23 ).
Always install a new lens gasket (P/N 79108600). Whenever
disassembling the IntelliBrite light assembly. Failure to do so may
permit water to leak into the assembly which could cause: (a) an electrical hazard
resulting in death or serious injury to pool users, installers, or others due to electrical
shock, or (b) breakage of the lens, which likewise could result in serious injury to pool
users, installers, or bystanders, or in damage to property.
Pilot screw (bronze)
IntelliBrite 5G Spa Light
19
