Pentair IntelliBrite Installation Guide

3
WARNINGS AND IMPORTANT SAFETY PRECAUTIONS
Be sure the pool electrical system conforms with all requirements of all local codes
and ordinances. A qualied electrician must install the electrical system to meet or
exceed those requirements before the IntelliBrite Controller is installed. The electri-
cian should also consult the local building department regarding local codes. Examples
of requirements are listed below:
• The IntelliBrite Controller must be installed by a qualied electrician,
according to local code requirements.
• The IntelliBrite Controller must be provided with a fail-proof ground as
required by any applicable local codes.
• Do not install the IntelliBrite Controller within 3 meters of any body of
water.
• The IntelliBrite Controller should be mounted at least 30 cenmeters
above the water and ground level.
• Do not exceed the maximum rangs of individual components, wiring
devices, and current carrying capacity of conductors.
• The lighng circuit must have a Ground Fault Circuit Interrupter (GFCI),
and an appropriately rated circuit breaker.
• The light xture and all metal items within 1.5 meter of the pool must be
properly electrically bonded.
• The IntelliBrite Controller must be properly electrically bonded and
grounded.
• Do not submerge the IntelliBrite Controller.
• Do not connect two or more IntelliBrite Controller together.
• This device is IP54 rated.
English
IntelliBrite Controller kit contents
The following items are included in the IntelliBrite Controller kit:
• IntelliBrite Controller, 230 VAC, CE, P/N 620139
• Gasket, P/N 619763
• Knob, P/N 690026
• Door, P/N 690027
• Screw kit, P/N 619764
• Outlet box (P/N 650185) (see page 6)
• Installaon and User’s Guide (this manual)
Related manuals - Download the IntelliBrite LED Pool Light Installaon and User’s Guide
(P/N 619931) at: hp://www.pentairpooleurope.com

Pentair IntelliBrite Specifications

General

Housing Material	Polymer
Lens Material	Polycarbonate
IP Rating	IP68
Color Options	Multiple
Wattage	40W
Voltage	12V or 12 VAC
Control	Automation System
Installation	In-ground Pool
Lifespan	30, 000+ hours
Type	LED Pool Light
Light Color	Color changing
