Pentair IntelliBrite Installation Guide

5
Selecng a Light Show or Fixed Color
Note: When the IntelliBrite LED light(s) are powered on, a white light will
momentarily illuminate, followed by the selected color, unless the HOLD or RECALL
feature was previously enabled.
To select a color light show mode or xed color mode, rotate the dial so that it points
to the desired selecon.
The color mode selecons are described below starng clockwise from the
9 o’clock posion:
Light Show Mode
• SAm Mode: Cycles through white, magenta, blue and green colors (emulates
the Pentair Water Pool and Spa SAm
®
light).
• Party Mode: Rapid color changing building energy and excitement.
• Romance Mode: Slow color transions creang a mesmerizing and
calming eect.
• Caribbean Mode: Transions between a variety of blues and greens.
• American Mode: Patrioc red, white and blue transion.
• California Sunset Mode: Dramac transions of orange, red and
magenta tones.
• Royal Mode: Richer, deeper color tones.
Fixed Colors
• Blue: Fixed color.
• Green: Fixed color.
• Red: Fixed color.
• White: Fixed color.
• Magenta: Fixed color.
Hold and Recall Feature
Note: When the IntelliBrite LED light(s) are powered on, a white light will
momentarily illuminate, followed by the selected color, unless the HOLD or RECALL
feature was previously enabled.
Hold buon/LED: Press this buon (LED on) to capture and save a color eect while
displaying one of the light show modes. When the buon is pressed, the LED will be
on, indicang that the color eect is captured.
Recall Buon/LED: Use this buon (LED on) to acvate the last saved color
eect. When the buon is pressed, the LED will be on, indicang that the color
eect is being displayed.
English

Pentair IntelliBrite Specifications

General

Housing Material	Polymer
Lens Material	Polycarbonate
IP Rating	IP68
Color Options	Multiple
Wattage	40W
Voltage	12V or 12 VAC
Control	Automation System
Installation	In-ground Pool
Lifespan	30, 000+ hours
Type	LED Pool Light
Light Color	Color changing
