Wiring an IntelliBrite Controller to IntelliBrite LED Lights
Maximum waage when using mulple lights with controller
When using mulple IntelliBrite LED lights, the total allowable light waage is 300 Was
maximum. Up to 6 IntelliBrite 5g lights can be connected to one IntelliBrite Controller.
NOTE : When using mulple IntelliBrite lights, make sure to wire the 12V transformer
accordingly.
To wire mulple 230 VAC IntelliBrite LED Lights to an IntelliBrite Controller:
1. Route the power supply cable, up through the PG nut and into the outlet box.
Do the same for the cable going to the IntelliBrite ransformer.
2. Strip the ends of the three light conductors, and the three power supply wires.
3. Connect the two ground wires (green/yellow) to each other.
4. Connect the (in most cases) blue NEUTRAL wires from the light and power
supply cable together with the white cable on the IntelliBrite Controller.
5. Connect the remaining cable from the power supply to the black cable of the
IntelliBrite Controller.
6. Connect the remaining cable from the transformer to the red cable of the
IntelliBrite Controller.
7. Aer the wiring has been completed and checked, proceed to “Installing the
Controller in the Outlet box”.
IMPORTANT! When installing 12 VAC IntelliBrite LED lights, connect the lights to the
secondary 12 VAC output of the step down transformer, then connect the IntelliBrite
Controller to the 230 VAC primary input of the step down transformer.
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION
TURN power OFF at circuit breaker - Always
disconnect power to the pool light at the circuit
breaker before servicing the light. Failure to do
so could result in death or serious injury to
installer, service person, pool users, or others due
to electrical shock.
