IntelliBrite
®
Controller System Wiring Diagram
IMPORTANT! When installing 12 VAC IntelliBrite LED lights, connect the lights to the
secondary 12 VAC output of the step down transformer, then connect the IntelliBrite
controller to the 230 VAC primary input of the step down transformer.
English
