Pentair IntelliBrite Installation Guide

4
IntelliBrite
®
Controller Overview
The IntelliBrite Controller provides complete control of Pentair Aquac Systems
IntelliBrite underwater LED (light-eming diode) lights. It’s easy to select a lighng
feature, just dial in any one of the pre-programmed color light shows or xed colors.
Using the Hold and Recall buons you can also create endless unique lighng eects.
The IntelliBrite Controller can control individual or mulple IntelliBrite LED lights.
Mulple IntelliBrite LED lights can be connected via a juncon box to an IntelliBrite
Controller so that all lights can be switched on and o together.
Controls and Buons
The IntelliBrite Controller controls, buons and LEDs are shown below:
PRINTED ON: 7/29/2009, 600054_ctlg pics.SLDASM
Power
ON/OFF Switch
RECALL buon
and LED
Dial
(for selecng color
light shows and xed
colors)
Color show
Selecons
Door
HOLD buon
and
LED
IntelliBrite
®
Controller
The IntelliBrite controller is a 230 VAC device, DO NOT connect 12 VAC
IntellilBrite pool/spa LED lights directly to the IntelliBrite controller, use an appropriate
step down transformer between the controller and lights.
English

Pentair IntelliBrite Specifications

General

Housing Material	Polymer
Lens Material	Polycarbonate
IP Rating	IP68
Color Options	Multiple
Wattage	40W
Voltage	12V or 12 VAC
Control	Automation System
Installation	In-ground Pool
Lifespan	30, 000+ hours
Type	LED Pool Light
Light Color	Color changing
