How to Add Salt to the Pool
CAUTION - FOR ALL NEWLY CONSTRUCTED OR RESURFACED PLASTER POOLS: Do not operate
the SCG with newly poured or resurfaced pool plaster. Salt is a corrosive element and severe salt damage can
occur to your pool. Wait at least ONE (1) MONTH after construction to allow plaster to cure before adding salt
and operating SCG. Follow the pool surface manufacturer’s guidelines for your specific pool. FOR NEW VINYL
LINER POOLS, contact the manufacturer for recommended guidelines before adding salt and operating the
SCG.
1. Check salt level in pool water before adding any salt to pool.
2. Determine the amount of salt from the following charts.
3. Slowly pour in the salt around the outer perimeter of the pool for quick and even distribution. To
avoid clogging t
he filter or damaging pool related equipment and surrounding surfaces, do not
add salt through the skimmer or surge tank.
4. Brush the pool bottom and allow water to circulate for 24 hours to dissolve salt completely.
5. After 24 hours, verify correct salt level reading by checking the LED indicators on the IntelliChlor
SCG and by a separate reliable test method.
6. Power on the IntelliChlor
®
Salt Chlorine Generator and set the Sanitizer Output level to the proper
setting to maintain the appropriate free chlorine levels in the pool and spa water (i.e., within the
1-3 ppm for pools and 3-5 ppm for spas).
Table 1. Approximate pounds (lbs) / kilogram (kg) of salt needed to obtain 3,400 ppm in pool
CHART FOR ADDITION OF SALT TO 3400 PPM
Pool Gallons 0 ppm 250 ppm 500 ppm 750 ppm 1000 ppm 1250 ppm 1500 ppm 1750 ppm 2000 ppm 2250 ppm 2500 ppm 2800 ppm 3000 ppm
10,000
lbs
284.00 263.12 242.24 221.35 200.47 179.59 158.71 137.82 116.94 96.06 75.18 50.12
33.41
kg
128.82 119.35 109.88 100.41 90.93 81.46 71.99 62.52 53.04 43.57 34.10 22.73
15.16
12,000
lbs
340.80 315.74 290.68 265.62 240.56 215.51 190.45 165.39 140.33 115.27 90.21 60.14
40.09
kg
154.59 143.22 131.85 120.49 109.12 97.75 86.39 75.02 63.65 52.29 40.92 27.28
18.19
14,000
lbs
397.60 368.36 339.13 309.89 280.66 251.42 222.19 192.95 163.72 134.48 105.25 70.16
46.78
kg
180.35 167.09 153.83 140.57 127.31 114.05 100.78 87.52 74.26 61.00 47.74 31.83
21.22
16,000
lbs
454.40 420.99 387.58 354.16 320.75 287.34 253.93 220.52 187.11 153.69 120.28 80.19
53.46
kg
206.12 190.96 175.80 160.65 145.49 130.34 115.18 100.03 84.87 69.72 54.56 36.37
24.25
18,000
lbs
511.20 473.61 436.02 398.44 360.85 323.26 285.67 248.08 210.49 172.91 135.32 90.21
60.14
kg
231.88 214.83 197.78 180.73 163.68 146.63 129.58 112.53 95.48 78.43 61.38 40.92
27.28
20,000
lbs
568.00 526.24 484.47 442.71 400.94 359.18 317.41 275.65 233.88 192.12 150.35 100.24
66.82
kg
257.64 238.70 219.76 200.81 181.87 162.92 143.98 125.03 106.09 87.14 68.20 45.47
30.31
22,000
lbs
568.00 526.24 484.47 442.71 400.94 359.18 317.41 275.65 233.88 192.12 150.35 100.24
66.82
kg
257.64 238.70 219.76 200.81 181.87 162.92 143.98 125.03 106.09 87.14 68.20 45.47
30.31
24,000
lbs
681.60 631.48 581.36 531.25 481.13 431.01 380.89 330.78 280.66 230.54 180.42 120.28
80.19
kg
309.17 286.44 263.71 240.97 218.24 195.51 172.77 150.04 127.31 104.57 81.84 54.56
36.37
28,000
lbs
795.20 736.73 678.26 619.79 561.32 502.85 444.38 385.91 327.44 268.96 210.49 140.33
93.55
kg
360.70 334.18 307.66 281.14 254.61 228.09 201.57 175.05 148.52 122.00 95.48 63.65
42.44
30,000
lbs
852.00 789.35 726.71 664.06 601.41 538.76 476.12 413.47 350.82 288.18 225.53 150.35
100.24
kg
386.47 358.05 329.63 301.22 272.80 244.38 215.97 187.55 159.13 130.72 102.30 68.20
45.47
IntelliChlor Salt Chlorine Generator Installation and User’s Guide
