OPERATING THE PUMP 2/20
PUMP OPERATING MODES
The IntelliFlo
®
VSD2 Pump can be programmed in three different modes:
Speeds 1-4 can be programmed in all three modes.
Speeds 5-8 can only be programmed in Schedule mode since there are no buttons on the
control panel for Speeds 5-8. The default setting for Speeds 5-8 is “Disabled”.
Manual
Assigns a speed to one of the four speed buttons on the control panel. This mode can only be
used for speeds 1-4. Speeds 1 and 2 are Manual by default.
To operate in manual mode, press one of the four speed buttons and then press the Start/
Stop button. The pump will run the assigned speed assigned to that speed button.
Egg Timer
Speeds 1-4 can be programmed to run at a certain speed and for a duration of time once a
program button is pressed.
Programs 3 and 4 are Egg Timers by default. If you desire a different method of operation,
programs 3 and 4 can be changed to Manual mode in the control menu.
To operate in Egg Timer mode, press a speed button and then press Start/Stop. The pump
will run that setting for the set amount of time and then turn off.
Schedule
Program speeds 1-8 start and stop at a specific time during a 24 hour period. Speeds
programmed in Schedule mode will override any manually selected speed once the next
Schedule command commences.
13
Program Menu Tree Options
Speed 1 (1-4)
Manual
Schedule
Egg Timer
Set Speed - Default: MANUAL
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
Speed 5 (5-8)
Schedule
Set Speed
Set Start Time
Set Stop Time
Disabled
Default: Disabled
