OPERATING THE PUMP 8/20
SPEEDS 1-8 (SCHEDULE A TIME TO RUN THE PUMP)
PUMP OPERATING MODES
The IntelliFlo
®
VSD2 pump can be programmed in three different modes: manual, schedule
and egg timer. Speeds 1-4 can be programmed in all three modes. Speeds 5-8 can only be
programmed in schedule mode since there are no buttons on the control panel for speeds
5-8. The default setting for speeds 5-8 is disabled.
Speed Menu Tree Options
Speed 1 (1-4)
Manual
Schedule
Egg Timer
Set Speed - Default: MANUAL
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
Speed 5 (5-8)
Schedule
Set Speed
Set Start Time
Set Stop Time
Disabled
Default: Disabled
Manual
Assigns a speed to one of the four (4) speed buttons on the control panel. This mode can only
be used for speeds 1-4. Speeds 1 and 2 are manual by default.
To operate in manual mode, press one of the four speed buttons and then press the start/
stop button. The pump will run the assigned speed to that speed button.
Egg timer
Speeds 1-4 can be programmed to run at a certain speed and for a duration of time once a
speed button is pressed.
Speeds 3 and 4 are egg timers by default. If you desire a different method of operation,
speeds 3 and 4 can be changed to manual mode in the control menu.
To operate in egg time mode, press a speed button and then press start/stop. The pump will
run that setting for the set amount of time and then turn off.
Schedule
Program speeds 1-8 start and stop at a specific time during a 24 hour period. Speeds
programmed in schedule mode will override any manually selected speed once the next
schedule command begins.
