INTELLIFLO
®
VSF Variable Speed and Flow Pump Installation and User’s Guide
10
INTELLIFLO
®
VSF Variable Speed and Flow Pump Installation and User’s Guide
Pump Menu: Settings
Set Date and Time
The time controls all scheduled times, functions, and
programmed cycles and stores the correct time for up
to 96 hours after power is turned off. Reset if the power
is off longer than 96 hours.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Date and
Time”. Press Select.
5. Press Select again and use Up or Down arrows to
set the date.
6. Press Save to save user input and return to "Date
and Time."
7. Use the Up or Down arrows to scroll to “Time”. Press
Select.
8. Use the Up or Down arrows to scroll to edit the time.
Note: To set AM/PM or a 24 hour clock see the next
section "Set AM/PM or 24 Hour Clock."
9. Press Save to save. To cancel any changes, press
Back to exit without saving.
10. Press Back to exit.
Set AM/PM or 24-Hour Clock
To change the time from a 12 hour clock (AM/PM) to a
24 hour clock:
1. Press Menu.
2. Press Select to select “Settings”.
3. Use the Up or Down arrows to scroll to “Date and
Time". Press Select.
4. Use the Up or Down arrows to scroll to "AM/PM".
Press Select.
5. Use the Up or Down arrows to scroll to choose
between 24 hr. and AM/PM.
6. Press Save to save. To cancel any edits, press Back
to exit without saving.
7. Press Back to exit.
Set Minimum Speed (RPM)
The minimum pump speed can be set from 450 RPM
to 1700 RPM. The default setting is 450 RPM.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Min/Max”.
Press Select.
5. Use the Up or Down arrows to scroll to “Set Min Spd”.
6. Press Select to change the setting. The cursor will
appear in the first number column (ones).
MENU
Note: Maximum Speed will limit Priming Speed, except
in one case. If the Maximum Speed is set below the
lowest available Priming Speed (2400 RPM) then
the pump will exceed the Maximum Speed while the
priming feature is running. This prevents the pump from
having trouble priming if the Maximum Speed is set
this low. If this is a problem, priming can be disabled in
the Priming Menu (see “Priming” section on page 17).
Set Minimum Flow Rate (GPM)
The minimum programmed flow rate can be set from 20
GPM to 70 GPM.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Min/Max”
and press Select.
5. Use the Up or Down arrows to scroll to “Set Minimum
Flow”.
6. Press Select to change the setting. The cursor will
appear in the first number column (ones).
7. Press the Up or Down arrows to edit the minimum
flow rate setting from 20 to 70 GPM.
8. Press Save to save. To cancel, press Back to exit
edit mode without saving.
9. Press Back to exit.
7. Press the Up or Down arrows to edit the minimum
speed setting from 450 to 1700 RPM.
8. Press Save to save. To cancel, press Back to exit
edit mode without saving.
9. Press Back to exit.
Set Maximum Speed (RPM)
The maximum speed can be set from 1900 RPM to
3450 RPM (default is 3450). Use this setting to set the
maximum running speed of the IntelliFlo
®
VSF Variable
Speed and Flow Pump.
Note: Maximum and minimum speed settings, and the
associated alarms, remain active when in Flow mode.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Min/Max”.
Press Select.
5. Use the Up or Down arrows to scroll to “Set Max Spd”.
6. Press Select to change. The cursor will appear in
the first number column (ones).
7. Press Up or Down arrows to edit the maximum speed
setting from 1900 to 3450 RPM.
8. Press Save to save. Press Back to exit. To cancel,
press the Back to exit without saving.
