INTELLIFLO
®
VS+SVRS and INTELLIPRO
®
VS+SVRS Variable Speed Pump Installation and User’s Guide
EasyTouch System Load Center (front view)
Control panel
access screw
Control panel
access screw
High voltage
cover panel
Retaining screw
10. Close the control panel into its original position and secure it with the two access screws.
11. Install the high voltage cover panel and secure it with the two retaining screws.
12. Close the EasyTouch
®
Control System load center front door. Fasten the two spring latches.
13. Switch the power on to the EasyTouch control system load center.
