125 Pool and Spa Heater Installation and User’s Guide P/N 475114 Rev. F 9/2020
|
Gas Safety (Installation and Use) Regulations, (as amended).
It is the law that all gas appliances are installed by a competent person (e.g. a CORGI registered operative)
in accordance with Regulations.
Failure to install appliances correctly could lead to prosecution.
The installation of the Heater MUST also be in accordance with the current I.E.E.. Wiring Regulations, the
European Building Standards, the Bye Laws of the Local Water Undertaking, any relevant requirements of
the Local Authority, and Health and Safety document No 635, “Electricity at Work Regulations”.
Detailed recommendations are contained in the following British Standard Codes of Practice.
• Manufacturer’s Installation Instructions
• Local Gas Fitting Regulations
• Municipal Building Codes
• EN 437: 2003 + A1 (2009) Test Gases
- Test pressures appliances categories.
• EN 60335-2-102/A1 - Household and
similar electric appliances - Safety - 2- 2012
• BS 6891 Specification for installation of low
pressure gas pipe work.
• BS5482:1 Code of practice for domestic butane
and propane gas burning installations. Building
Regulations| Part L1.
• NOx Class 5
• Local Electrical Regulations
• Any other statutory regulations
• EN 15502-1 : 2012 Gas fired
heating boilers general
requirements test.
• BS 6644 : 2011 Specifications
for the installation and
maintenance of gas fired hot water
boilers between 70Kw - 1.8 mW, (2nd.
IMPORTANT NOTICE:
DO NOT directly connect any external control device to this appliance, unless noted in this Installation and
User’s Guide or recommended by the manufacturer. Any installed control device not recommended by
the manufacturer could violate the Gas Safety Regulations (the installation and use), the above described
regulations and the appliance warranty.
The manufacturer’s notices DO NOT supersede any legal requirements.
Installation must be in accordance with the code requirements:
CODE REQUIREMENTS / REFERENCES
1312
i |
Code Requirements / References
General Specifications
GAS TYPE:
GAS GROUP:
GAS SUPPLY PRESSURE:
TYPE OF APPLIANCE:
COUNTRY OF DESTINATION:
WARNING!
READ THE TECHNICAL INSTRUCTIONS BEFORE INSTALLING THIS APPLIANCE.
READ THE INSTALLATION AND USER’S GUIDE BEFORE LIGHTING THIS APPLIANCE.
0087
1312
6
0087
1312
THIS HEATER IS EQUIPPED TO BURN
OUTPUT
ALTITUDE
MINIMUM CLEARANCE FROM COMBUSTIBLE
CONSTRUCTION 15 CM REAR, 15 CM TOP, 15 CM SIDE.
DO NOT INSTALL THIS HEATER UNDER AN OVERHANG
LESS THAN 1 METER FROM THE TOP. THE AREA UNDER
THE OVERHANG MUST BE OPEN ON THREE (3) SIDES.
APPROVED FOR INDOOR AND OUTDOOR INSTALLATIONS.
ELECTRICAL COMPLIANCE: IN ACCORDANCE WITH LOCAL ELECTRICAL CODES.
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH THE EUROPEAN STANDARD INSTALLATION
CODES, AND WITH THE REQUIREMENTS OF THE AUTHORITY HAVING JURISDICTION.
REFER TO THE OPERATING INSTRUCTIONS FOR
APPROVED WATER TREATMENT.
TYPE G23
G20:
G31:
TEST POINT PRESSURE
MAX. WORKING PRESSURE
mbar
mbar
mbar
3.45 mbar
ELECTRICAL RATINGS:
VOLTS:
HERTZ:
AMPS:
12 A
APPLIANCE CATEGORY
COUNTRY OF DESTINATION
YEAR OF MANUFACTURE
MODEL NO.
SERIAL NO.
DESIGN AND MANFACTURED BY PENTAIR WATER POOL AND SPA, INC.
INPUT RATE
ORIFICE SIZE
MASTERTEMP
™
POOL HEATER
GAS
kW
mm
2000 m
kW
Label P/N
GB, BE, DE, FR
Hz
V
GAS SUPPLY PRESSURE:
G25:
mbar,
To Next Page
