76670 -10/12-
※ 2m AF chart have to be set as follows
1）Distance between chart and mount of camera --- 1,954.5mm
（＝1.9545m）
2）Chart should be set at perpendicularly against light axis of the lens
↓
[CCD POSITION ADJUST]
ADJUSTMENT
1) Alpha-CROSS --→- Dump Start --→ Adjustment --→ Stop
2) Beta-SQUARE --→- Dump Start --→ Adjustment --→ Stop
3) Focus --- Start -→- Next → Stop → Close
* When replaced M100, Click M100 button and then start adjustment
↓
POSITION CHECK
[AGC LEVEL ADJUST]
[UNIFORMITY ADJUST]
[FOCUS OFFSET ADJUST]
TEMP ADJUSTMENT（ Select /F → Input temperature→ Temp Adjust → Close）
HORIZONTAL・VERTICAL*
（START→ Adjust position of chart → STOP → ADJUST → Close）
5：EEPROM CHECKING
When finished all adjustment, click 5：EEPROM CHECKING
* When replaced T100, the following adjustment should be done additionally
6：BATTERY LEVEL ADJUST
Tools: Battery adaptor, Power supply (8V, 3A)
① Follow the screen
When open and close the battery cover, [Pc] will be displayed in the LCD panel of the camera
② Click Op and then start the correspond with camera. Display will change to「- - -」
③ Press BC Adjust and execute the adjustment
④ After finished the adjustment, press Close button
※ If the power turned ON again, execute above ②
7：SHUTTER SPEED ADJUST
Tools: Shutter tester
① Select the shutter tester
② Press RELESE button and release the shutter several times, also measure the data
③ Input Measurements data and press Input Data
④ After finished the adjustment, press Close button
Finish the [5：EEPROM CHECKING] and execute [End procedure]
To Next Page
