Table of Error Code 1 (SR unit adjustment)
SR unit adjustment, Table of Error Code (7– bb)
Error Code 
 (bb)
Contents
1
X MOVE ERROR
Lead wire is touching, connector contact NG, SR block NG
2
Y MOVE ERROR
〃
3 X DIR ERROR
〃
4 YL DIR ERROR
〃
Coil
5 YR DIR ERROR
〃
6 VREF ERROR connector contact NG Holl_Gain
7 IREF ERROR Lead wire is touching, Screw is stick on
8
RANGE OVER ERROR
〃
9 Ereki Limit ERROR
〃
Move_Range
10 Center Over ERROR
〃
11 Obit Core ERROR Weak connector contact, Bending flexible board
12 Obit Center ERROR
〃
Corner_Obit
13 Obit Corner ERROR
〃
15 "4HZ ERROR"
〃
16 "6HZ ERROR"
〃
Frequency
17 "10HZ ERROR"
〃
Gyro
14
GYRO VALUE
ERROR
Miss arranging gyro board lead wire
22 Reverse ERROR Coil is reversed
7












23 "0HZ ERROR" No use
Table of Error Code2 (SR unit adjustment)
SR gain adjustment, Table of Error Code (7 – bb)
Error Code 

(bb)

 
Contents
18 GYROWAVEERROR 
Gyro NG or condition of stage
Gyro
19 CHARTNOTCENTERERROR

Chart is not center of viewfinder
20 SRXERR 
Captured image is not right exposure
7
Caputure
21 SRYERR 〃
