Pentax 77420 - 3 Confirmation; Adjustment] Flow

77420 - 7/107 -
3. [IV. Confirmation/ Adjustment] Flow


2. Initialize when replace T100
*Writing Product firm ware [GM_FW]
*Writing initial Data [Initial Data Set]
3.SR adjustment I (SR unit adjustment)
[SR_Operation_Adjustment]
5. SLR function adjustment
[K-r_ PDCAdj]
[K-r_ SLR_Uni]
[K-r_ SLR_FI]
7. SR adjustment II (SR gain adjustment)
[K-r_SR_Gain]
6. Digital part adjustment
[K-r_ MTest]
8. Shutter speed adjustment by histogram
[K-r_PDCAdj]
Initial setting
[Initialize Set]
WDC adjustment
[K-r_ MTest]
9. Writing Warranty Record
When replace T100 or serial number
[Warranty_Record]
1. Battery consumption check
4. Function Check 1
AF check
Exposure mode/Shutter release
Capture/Playback
Flash
[Adj]Flash retract position
Diaphragm control/CMOS surface
10. Function check 2
Metering
Exposure
WB
AF check by taking picture
SR Function
(If already adjusted SR, not necessary)
CMOS Cleaning
FW (Firmware)
(Confirm version/Version up)
■General check ■Must execute when replace T100
■Optional
Image Shift adjustment
[Roration&Shift]
