77420 - 49/107 -
21-2. Preparation for adjustment
① Set focus mode to [MF].
② Connect AC adaptor to the camera.
③ Connect the camera to PC by USB cable then turn ON the power.
21-3. Adjustment (Kr PDCAdj)
①Double click [D_SLR_M100_3point.exe] in the [Kr_CCD_Adj_] Folder to start up software.
②Below screen will be displayed.↓
AF Focus Adjustment
Sensor Angle Adjustment
To Next Page
