77420 - 80/107 -
8-4.Procedure for adjustment (Kr_PDCAdj)
① Connect the camera and PC with USB cable and turn ON the camera.
② Double click [Kr_PDCAdjv204.exe] in [Kr_ PDCAdj] folder to start up software. ↓
③ Click [SHUTTER SPEED]. Then it can push the [INPUT] button.
④ Input shutter speed data (EX: 0.26ms) and click [Input Data] button.
⑤ If data is NG, input [0.26]and click [Input Data]. (⑤ become effective)
⑥ When completed the adjustment, click in order to [Close] → [Cl]”Unconnect” → [end] to finish the
program software.
⑦ [Confirm] confirm the deviation by histogram again and confirm the shutter speed should be within
below tolerance.
Tolerance for adjustment: 0.224~0.290mS(Standard:0.265mS, Tv4000)
⑧ [Confirm] confirm Tv6000by histogram. There is no big difference from Tv4000.
LV8 LV9
Shutter speed（mS）
1/4000 1/6000 1/4000 1/6000
ISO sensitivity ISO3200 ISO6400 ISO1600 ISO3200
To Next Page
