77420 - 82/107 -
9．[Adjustment] Image shift adjustment
[Required equipments]
□Programmed software for 77420 ---[Rotation&Shift_Ver]
□Exclusive cart for adjustment (Attached service manual etc) □Tripod (Set horizontal and vertical)
□String (Diameter: Approx.1mm) and weight (To set chart horizontal and vertical)
□50mm lens □PC (Windows Xp (SP2), with USB port equipped) □USB cable (I-USB17) □AC adaptor kit
□Remote control F
9-1.Confirm image
①Execute confirmation without connecting with PC.
②To avoid camera shaking and misalignment with chart, set the drive mode to [Remote Control] and set
Instant Review to [5sec].
③Align the viewfinder frame between red square and blue square as shown in figure below.
And set the camera at center of chart.
[Caution1] Direction of eye should be center of viewfinder. Camera should be set vertical against chart.
[Caution2] Viewfinder frame should be evenly for right, left, top and bottom against the chart.
And there is no tilting.
To Next Page
